FDK Twicell 2500mAh NIMH Button End AA Low Self Discharge Single Cell - Product Image

FDK Twicell 2500mAh NIMH Button End AA Low Self Discharge Single Cell

FDK (formerly Sanyo) Ultra high capacity AA Button End single cell.

Unlike Sanyo's other NiMH cells, these ultra high capacity AA cells should never be fast charged EVER. We recommend 70mah (or less) wall chargers (very slow overnight charging) only. Suggested maintenance charge rate 50-70mah. Manufacturer's listed internal resistance is 25mΩ.


Voltage: 1.2 Volts
Capacity: 2500mAh (maximum 2620mAh)
Chemistry: Nickel Metal Hydride - Ni-MH (Pre-charged)
Dimensions: Diameter 0.58"(14.35mm) x Height 1.99" (50.4mm)




SKU Number: RRC01H2500TWBE
Price: $6.00
Quantity:

Elite 1500mAh 2/3 A NiMH High Drain Cell - Product Image

Elite 1500mAh 2/3 A NiMH High Drain Cell

2/3 A size cell. Elite 1.2v 1500mah High Rate 2/3A NiMH high capacity, high discharge cells. Suggested charge rate non-peak detecting 150mah or less, peak detecting 700-2800mah.




SKU Number: RRC01H1500EL
Price: $5.00
Quantity:

NT12AAAM NiMH Cell ~ Last Cell left in stock! - Product Image

NT12AAAM NiMH Cell ~ Last Cell left in stock!

120mAh Single Cell. Last one in stock. No warranty no return. Discontinued by factory.




SKU Number: RRC01H0120
Price: $2.00
Quantity:

NT12AAAM NiMH Cell ~ Last Cell left in stock! - Product Image

NT12AAAM NiMH Cell ~ Last Cell left in stock!

120mAh Single Cell. Last one in stock. No warranty no return. Discontinued by factory.




SKU Number: RRC01H0120
Price: $2.00
Quantity:

FDK/Sanyo Twicell 700-AAA NiMH Cell - Product Image

FDK/Sanyo Twicell 700-AAA NiMH Cell

FDK (formerly Sanyo). Most popular cell for S-280 and S-300 machines. Ultra long duration for GWS IPS powered ships like the Pico Stick and Tiger Moth. Perfect in 8 cell packs for Zero, Mustang and Beaver. Normally used in the 3 to 6 amp range but has applications up to 8 amps for short burst in fun-fly models. NOT for S-400, although I have used one with a lower current 7.2V S-400 setup previously. AAA size cell. Manufacturers listed internal resistance is 35mohm.

FDK/Sanyo Twicell NiMH HR-AAAUC 700mAh Flat top cell Twicell Battery Single Cell 1.2 Volt

Capacity: 730 mAh
Discharge Rate: 1 Amp
Single Cell Length: 1.73"
Single Cell Diameter: 0.41"
Single Cell Weight: 0.43 ounces
Termination: Flat Top (Tech Cell for Battery Packs)

Suggested charge rate non-peak detecting 70mAh or less, peak detecting 350-700mAh. Slow charging is always recommended.


SKU Number: RRC01H0700
Price: $3.75
Quantity:

FDK (Sanyo) 1650 Flat End AA NiMH Cell - Product Image

FDK (Sanyo) 1650 Flat End AA NiMH Cell

FDK (formerly Sanyo) AA size cell. Perfect to build your RX and TX packs. Some uses for S-400, up to 14 amp range though not common. It is the same size as any "AA" cell, but with flat ends instead of button end. We carry these for those that desire to build their own custom soldered packs. The flat ends make it much easier to solder. These may function in some digital camera and similar devices but they may not due to missing "button". Manufacturers listed internal resistance is 25Ω.






SKU Number: RRC01H1650FE
Price: $4.95
Quantity:

FDK/Sanyo 2500mAh Single Cell  NIMH Button End AA Battery - Product Image

FDK/Sanyo 2500mAh Single Cell NIMH Button End AA Battery

FDK (formerly Sanyo) single cell Ultra high capacity AA battery. Weight 30.3g, 1.07oz. FDK/Sanyo AA HR6 size cell. Button end cell.

Unlike Sanyo's other NiMH cells, these ultra high capacity AA cells should never be fast charged EVER. We recommend 70mah (or less) wall chargers (very slow overnight charging) only. Suggested maintenance charge rate 50-70mah. Manufacturer's listed internal resistance is 25m.

Discontinued by FDK(Sanyo), see the new Twicell version



While supplies last!


SKU Number: RRC01H2500AABE
Price: $5.50
Quantity Available:  2
Quantity:

FDK 4000-4/3AU Long NiMH Cell - Product Image

FDK 4000-4/3AU Long NiMH Cell

Good cell for large applications up to 50 amps.
FDK(Sanyo) 4/3 long "AU" size cell.
Weight is 55g.

SKU Number: RRC01H4000
Price: $9.00
Quantity:

Elite 1.2V 4000mAh High Rate Sub C NiMH 43mm X 23mm - Product Image

Elite 1.2V 4000mAh High Rate Sub C NiMH 43mm X 23mm

Elite 1.2V 4000mAh High Rate Sub C NiMH.

Dimensions: 43mm X 23mm / 1.69"x.91"
Weight: 69.2g/2.4oz
Size: Sub C

May fit your screw-apart glow drivers (see notes below). Our most powerful Sub C size NiMH single cell.

Special Glow Driver use notes: Some glow drivers are smaller inside than others. These cells are double shrunk, removing outer layer of clear shrink takes off about .008" making od around .901 (22.88mm). Removing the inner printed layer of shrink gets the OD down to about .895" (22.733mm). The OD of the trusty CP2400 Nicad cell is about .877" (22.276mm). Measure the ID of your glow driver before ordering to be sure it will fit. Any cell may be run without shrink in aluminum glow drivers. Note date 01/04/12.

Suggested charge rate non-peak detecting 350mah or less, peak detecting .5 to 4 amps. (RX power wired packs are limited to 4 amps charge rate due to connector pins, the cell could sustain up to 10 amp peak charge rate with correct form charging, wiring and plugs.

DISCONTINUED, WHILE SUPPLIES LAST


SKU Number: RRC01H4000EL
Price: $5.75
Quantity Available:  3
Quantity:

FDK/Sanyo Twicell 1900mah Single Cell AA NIMH, Button Top - Product Image

FDK/Sanyo Twicell 1900mah Single Cell AA NIMH, Button Top

FDK(formerly Sanyo) single Twicell (formerly called Eneloop) NiMH AA Button End Cell.

Unlike FDK(Sanyo)'s other NiMH cells, these ultra high capacity AA cells should never be fast charged EVER. We recommend 70mah (or less) wall chargers (very slow overnight charging) only. Suggested maintenance charge rate 50-70mah. Manufacturers listed internal resistance is 25mΩ.

FDK HR-3UTG Twicell Battery - 1.2 Volt 1900mAh AA Ni-MH Button Top ( extending )

  • Chemistry: Nickel Metal Hydride - Ni-MH (Precharged)
  • Dimensions: Diameter 0.58"(14.35mm) x Height 1.99" (50.4mm)
  • Weight: 0.96 oz (27 g)
  • Termination: Button Top (Consumer Button)

SKU Number: RRC01H1900TWBE
Price: $6.00
Quantity:

FDK/Sanyo 2700mAh AU Single Cell - Product Image

FDK/Sanyo 2700mAh AU Single Cell

FDK (formerly Sanyo) AU 2700 NIMH Single Cell

Voltage: 1.2 Volts

Capacity: 2700mAh

Chemistry: Nickel Metal Hydride - Ni-MH

Dimensions: Diameter 0.67"(17.0mm) x Height 1.97" (50.0mm)

Weight: 0.99 oz (28 g)

Termination: Flat Top (Tech Cell for Battery Packs)

Suggested charge rate non-peak detecting 270mah or less, peak detecting 1350-4000mah.
4 amps is the max charge rate through hobby pins.






SKU Number: RRC01H2700A
Price: $6.50
Connector
Quantity:

FDK/Sanyo 1000mah NiMH AAA Single cell 1.2V Button Top - Product Image

FDK/Sanyo 1000mah NiMH AAA Single cell 1.2V Button Top

FDK (formerly Sanyo) AAA NiMH HR-4U FDK 1.2V 1000mah Button top Cell is in FDK dark green shrink.

Suggested charge rate non-peak detecting 50 mah or less. We do not recommend fast charging this cell by any method.

FDK HR-4U Twicell Battery - 1.2 Volt 1000mAh AAA Ni-MH

  • Dimensions: Diameter 0.42"(10.5mm) x Height 1.76" (44.5mm)
  • Weight: 0.46oz (13g)
  • Termination: Button Top (Consumer Button)

SKU Number: RRC01H1000BE
Price: $3.75
Quantity:

FDK Twicell 1.2V 3000mAh High Discharge Rate Sub C NiMH 43.5mm X 23.0mm - Product Image

FDK Twicell 1.2V 3000mAh High Discharge Rate Sub C NiMH 43.5mm X 23.0mm

Twicell 1.2V 3000mAh High Rate Sub C NiMH.

May fit your screw-apart glow drivers (see notes below). Our most powerful Sub C size NiMH single cell.

Notes:
Some glow drivers are smaller inside than others. These cells are double shrunk, removing outer layer of clear shrink takes off about .008" making od around .901 (22.88mm). Removing the inner printed layer of shrink gets the OD down to about .895" (22.733mm). The OD of the trusty CP2400 Nicad cell is about .877" (22.276mm). Measure the ID of your glow driver before ordering to be sure it will fit. Any cell may be run without shrink in aluminum glow drivers. Note date 01/04/12.

Suggested charge rate non-peak detecting 300mah or less, peak detecting .5 to 4 amps. (RX power wired packs are limited to 4 amps charge rate due to connector pins, the cell could sustain up to 10 amp peak charge rate with correct form charging, wiring and plugs.


FDK's original electrode manufacturing process, coupled with specialized current collectors minimize internal impedance, which in turn enables high-rate discharging and guarantees a stable discharge voltage.

Dimensions: 43.5mm High x 23.0mm Diameter

Weight: 0.14 oz (59 g)

Size: Sub C

Nominal Voltage: 1.2V

Typical Capacity: 3000mAh

Minimum Capacity: 2700mAh*
     *Minimum capacity when a single cell is discharged at 0.2lt after being charged at 0.1lt for 16 hours.

Quick Charge Current: 3000mAh*
     *Typical capacity when a single cell is discharged at 0.2lt after being charged at 0.1lt for 16 hours.

Time: 1.1h



Coming soon!


SKU Number: RRC01H3000TW
Price: $9.00
Quantity:

FDK/Sanyo 2500mAh 4.8V 4-Cell NIMH Button End AA Battery - Product Image

FDK/Sanyo 2500mAh 4.8V 4-Cell NIMH Button End AA Battery

FDK (formerly Sanyo) cell Ultra high capacity AA battery. Weight 30.3g, 1.07oz. FDK/Sanyo AA HR6 size cell. Button end cell.

Unlike Sanyo's other NiMH cells, these ultra high capacity AA cells should never be fast charged EVER. We recommend 70mah (or less) wall chargers (very slow overnight charging) only. Suggested maintenance charge rate 50-70mah. Manufacturer's listed internal resistance is 25m.

Discontinued by FDK(Sanyo), see the new Twicell version



While supplies last!


SKU Number: RRC04H2500AABE
Price: $23.00
Output Connector
Shape Configuration
Quantity:
